SXDOOL 9225 92x92x25mm OEM DC Fan Platform
SXDOOL 9225 92x92x25mm DC axial fan for industrial PCs and power supplies. Confirm DC voltage, speed, airflow/static pressure, noise, bearing, cable, connector, signal and quantity with SXDOOL for OEM samples, cable, connector, bearing, label and batch RFQ review.
| Quantity | 100-999pieces, 1000-4999pieces, >= 5000 pieces |
|---|
9225 specification status and release evidence
This disclosure separates published performance data from release-controlled evidence so procurement and engineering teams can avoid substituting unverified family claims for the exact configuration.
| Material / flammability status | The exact frame and impeller polymer trade name, resin grade and UL 94 flammability class are not confirmed by current model-specific public evidence. These values must be stated on the approved drawing and BOM before sample or production release; no generic UL94V-0 claim is applied here. |
|---|---|
| Model-specific release evidence | Approved DC fan drawing, frame and impeller BOM, exact voltage-grade current, pressure-flow curve, acoustic condition, bearing code, signal and wiring definition, connector and final inspection plan. |
| Quality and traceability evidence | SXDOOL / SENSDA ELECTRONICS LIMITED applies ISO 9001:2015 quality-management controls. Dynamic Balancing and 100% End-of-Line Testing records can be reviewed against the approved production control plan for the released configuration. |
| Evidence request | Request the controlled drawing, BOM or material declaration, applicable performance curve, wiring definition and inspection record for 9225 from david@sxdool.com before qualification. |
Review quality assurance, factory capabilities, or submit a model-specific RFQ. External inquiry: david@sxdool.com.
SXDOOL 9225 OEM configuration hub for 92x92x25mm DC fans
Engineering summary: This page is the configuration gateway for a 92x92x25mm DC axial fan project. It does not define one universal voltage, airflow, pressure, current, speed, noise, bearing, cable, connector, or signal set; SXDOOL assigns the production model after the engineering requirements are frozen.
| Platform reference | SXDOOL 9225 configurable DC axial fan platform |
|---|---|
| Dimensions | 92x92x25mm nominal frame; approved drawing controls the mounting interface |
| Voltage | Project-selected; define 5V, 12V, 24V, 48V, or other reviewed requirement before model assignment |
| Airflow / static pressure | Selected from the required duty point and system resistance; no universal CFM or mmH2O value is asserted on this hub page |
| Speed / noise | Selected from the thermal and acoustic target; no universal RPM or dBA value is asserted |
| Current / power | Determined by the approved voltage and motor grade; include startup-current margin in the host design |
| Bearing | Sleeve or ball-bearing project option; final suffix and lifetime basis require the approved production specification |
| Material / flammability boundary | Catalog family reference: plastic frame and impeller, UL94V-0. Final material and documentation follow the approved configuration |
| Cable / connector / signal | Cable length, lead exit, connector, polarity, PWM, FG, RD, auto-restart, and label are project-controlled options |
| Best-fit buyer intent | OEM teams that know the 92x92x25mm mechanical envelope but need SXDOOL to map heat load, system resistance, voltage, acoustic limit, and interface requirements to a production SKU |
| Manufacturer and quality review | SENSDA ELECTRONICS LIMITED / SXDOOL. ISO 9001:2015 quality-management documentation, OEM/ODM cable and connector requirements, Dynamic Balancing, and 100% End-of-Line Testing can be reviewed against the approved production control plan. |
| Source and qualification boundary | This hub intentionally avoids a single numeric performance claim. Final values come from the selected model drawing, approved sample, and current controlled datasheet. |
Model and configuration table
| RFQ input | Required engineering detail |
|---|---|
| Thermal duty | Heat load, maximum component and ambient temperatures, altitude, and duty cycle |
| Airflow path | Required airflow or pressure, system-resistance estimate, filters, guards, heat sinks, inlet, and outlet geometry |
| Electrical interface | Voltage and tolerance, startup limit, cable, connector, pinout, PWM, FG, RD, auto-restart, and protection expectations |
| Mechanical interface | Frame depth, mounting holes, lead exit, airflow direction, guard/filter stack, and available inlet clearance |
| Commercial control | Quantity, sample plan, label, packaging, compliance documents, approved drawing revision, and acceptance criteria |
Engineering release rule: Catalog values are typical reference data under nominal test conditions. The current approved drawing, controlled datasheet, sample label, and validated equipment test govern the final purchasable configuration.
Model-specific engineering FAQ
Why does this 9225 page not publish one universal CFM value?
It is a project-configuration hub rather than a single frozen SKU. A 9225 frame can use different voltage, motor, speed, bearing, and signal combinations, so SXDOOL should select the performance grade from the customer duty point and issue an approved model drawing.
Which duty point, supply voltage, PWM or FG signal, wiring and connector data are needed for a 9225 recommendation?
Provide heat load, ambient and maximum component temperature, system resistance or airflow path, voltage, acoustic limit, duty cycle, bearing expectation, cable, connector, control/feedback signals, quantity, and compliance-document needs.
How does the sample approval process prevent mixed 9225 variants?
The approved sample should be tied to a complete model code, drawing revision, label, voltage, current, speed/airflow grade, bearing, cable, connector, pinout, signal behavior, inspection plan, and packaging reference. Purchase orders should repeat those controls.
When should an engineer compare the 9225 frame with a 9238 configuration?
Evaluate 9238 when the required duty point cannot be met through the 25mm frame at acceptable current, speed, and noise, and the equipment can accept the extra 13mm depth. Confirm both candidates against the same system curve.
Continue with the fan selector, review review standard 9225 catalog grades, review pressure-oriented 9225 grades, or submit a model-specific RFQ.
Brand: SXDOOL. English company name: SENSDA ELECTRONICS LIMITED. Chinese company name: 广州市盛煊达电子科技有限公司. Chinese pinyin: Guangzhoushi Shengxuanda Electronics Technology Co.,Ltd. External inquiry: david@sxdool.com.
