SXDOOL #803 White 150x150mm IP54 Filter Fan Kit
SXDOOL #803 White 150x150mm IP54 Filter Fan Kit. White #803 150x150mm IP54 enclosure filter fan kit for control cabinets. Confirm 115V/230V, cutout, airflow direction and quantity. Source-factory OEM/ODM customization and batch RFQ review are available.
SXDOOL #803 White IP54 enclosure filter fan kit
Engineering summary: a 150x150mm nominal cabinet ventilation format for 115V or 230V project review, combining a removable filter grille with a 120x38mm AC/EC fan platform. Final airflow performance depends on the selected fan, filter condition, and enclosure resistance.
| Product reference | #803 White enclosure filter fan kit |
|---|---|
| Nominal grille format | 150x150mm |
| Fan platform | 120x38mm AC / EC platform; final model follows the approved quotation |
| Voltage options | 115V / 230V project options; confirm one approved input specification |
| Ingress protection | IP54 tested to IEC 60529: IP5X dust-protected and IPX4 splash-water protected |
| Test evidence | Report TST20250201498-IPR, Dongguan True Safety Testing Co., Ltd., issued February 27, 2025 |
| Airflow and static pressure | No universal numeric duty point is published for every fan/filter combination. Validate the selected fan with clean and service-condition filter pressure drop. |
| Noise, current, and power | Confirm against the selected 115V or 230V fan model and approved production specification. |
| Filter and material | Replaceable filter media. Filter grade and grille material must follow the approved drawing or quotation; no universal grade is asserted on this page. |
| Panel cutout | Confirm the approved drawing, panel thickness, tolerance, gasket compression, and service clearance before enclosure machining. |
| Best-fit applications | White and light-grey automation panels, clean industrial enclosures, and equipment where the ventilation cover should visually integrate with a light enclosure finish. |
| Manufacturer and quality review | SENSDA ELECTRONICS LIMITED / SXDOOL. ISO 9001:2015 quality-management documentation, OEM/ODM requirements, Dynamic Balancing of the selected fan subassembly, and 100% End-of-Line Testing can be reviewed against the approved production control plan. |
SKU-specific engineering FAQ
When is the white #803 filter fan kit the better enclosure choice?
Choose the white version when a light-colour ventilation cover must integrate with white or light-grey control cabinets. Colour selection does not replace the engineering review of cutout, gasket, fan duty point, and installation environment.
Does the white cover change the published IP54 test boundary?
No. The verified claim remains IP54 under IEC 60529 for the tested assembly: IP5X dust-protected and IPX4 splash-water protected. The completed enclosure result still depends on panel cutout, gasket compression, mounting, wiring penetrations, and maintenance.
What should the maintenance plan cover for this white filter fan kit?
Define inspection and filter-service intervals from the actual dust loading and operating environment. A loaded filter increases system resistance, so qualification should compare clean-filter and service-condition airflow before batch approval.
Which data should be confirmed before a #803 white sample is approved?
Confirm 115V or 230V project input, panel cutout drawing, panel thickness, airflow direction, fan duty point, cable or terminal requirement, filter media, colour, service access, quantity, and installation environment.
For the IP54 report, drawing review, sample validation, or a batch quotation, contact david@sxdool.com. Continue with the control-cabinet cooling guide or the fan selector.
