SXDOOL 9238 92x92x38mm 24V High-Speed DC Fan
SXDOOL 9238 92x92x38mm DC axial fan for compact servers and filtered boxes. Confirm DC voltage, speed, airflow/static pressure, noise, bearing, cable, connector, signal and quantity with SXDOOL for OEM samples, cable, connector, bearing, label and batch RFQ review.
SXD9238M2B 24V high-speed voltage-specific qualification page
Engineering summary: This page identifies a 92x92x38mm, 24V high-speed DC fan for industrial equipment. The public page does not establish one verified current, speed, airflow, pressure, or noise set, so those fields remain drawing-controlled rather than inherited from another 9238 listing.
| Product / page reference | SXD9238M2B page identifier; approved drawing required |
|---|---|
| Fan family | Brushless DC axial fan |
| Dimensions | 92x92x38mm |
| Rated voltage | 24V DC |
| Speed | High-speed page classification; exact RPM requires the approved model specification |
| Airflow | Requires approved model datasheet or P-Q curve; no family value is copied onto this voltage-specific page |
| Static pressure | Requires approved model datasheet or P-Q curve |
| Noise | Requires approved model test reference and installation validation |
| Current / power | Requires approved model drawing; include startup-current margin |
| Bearing / lifetime | Requires approved model suffix and controlled specification |
| Cable / connector / signals | Requires approved drawing and interface specification; do not infer from image or wire colour |
| Material / flammability boundary | Catalog 9238 family reference: plastic frame and impeller, UL94V-0. Confirm the exact production configuration and documentation |
| Page differentiation | This is a voltage-specific commercial configuration. Use the family page for range comparison, then obtain the approved SXD9238M2B drawing for release. |
| Manufacturer and quality review | SENSDA ELECTRONICS LIMITED / SXDOOL. ISO 9001:2015 quality-management documentation, OEM/ODM cable and connector requirements, Dynamic Balancing, and 100% End-of-Line Testing can be reviewed against the approved production control plan. |
| Source and qualification boundary | Published page identity is retained; unverified SKU-level numeric claims are deliberately marked for drawing confirmation to prevent cross-page specification leakage. |
Model and configuration table
| Release checkpoint | Required evidence |
|---|---|
| Identity | Page identifier, sample label, gallery model, approved drawing, and purchase model agree |
| Performance | Current, startup profile, RPM tolerance, airflow, P-Q curve, pressure, noise, and temperature limits |
| Interface | Voltage, polarity, wire gauge, cable length, connector, pinout, lead exit, PWM, FG, RD, and auto-restart behavior |
| Acceptance | Thermal, vibration, acoustic, blocked-airflow, restart, end-of-line, label, and packaging criteria |
Engineering release rule: Catalog values are typical reference data under nominal test conditions. The current approved drawing, controlled datasheet, sample label, and validated equipment test govern the final purchasable configuration.
Model-specific engineering FAQ
Which missing values must be confirmed before the 24V 9238 fan can enter a bill of materials?
Confirm rated and startup current, speed tolerance, airflow and P-Q curve, noise reference, bearing, protection features, cable, connector, polarity, signal options, lifetime basis, operating temperature, and label revision on the approved drawing.
How should a 24V high-speed fan be sized for a power converter?
Calculate heat load and allowable temperature rise, estimate or measure the converter pressure loss, and select the operating point from approved fan-curve data. Then validate current, startup, hotspot temperature, vibration, and acoustic performance in the production airflow path.
Why should procurement not use the gallery filename as the model specification?
Media filenames help asset management but are not controlled engineering documents. The commercial page identifier, approved drawing, sample label, and purchase specification must agree before batch approval.
What supply checks are unique to a 24V high-speed 9238 application?
Check the 24V rail tolerance, simultaneous fan startup, transient current, connector and harness rating, voltage drop, reverse-polarity strategy, controller ground, and any alarm or tach interface using the approved sample.
Continue with the fan selector, review review the multi-voltage 9238 family table, compare the 12V 4600RPM page, or submit a model-specific RFQ.
Brand: SXDOOL. English company name: SENSDA ELECTRONICS LIMITED. Chinese company name: 广州市盛煊达电子科技有限公司. Chinese pinyin: Guangzhoushi Shengxuanda Electronics Technology Co.,Ltd. External inquiry: david@sxdool.com.
9238 specification status and release evidence
This disclosure separates published performance data from release-controlled evidence so procurement and engineering teams can avoid substituting unverified family claims for the exact configuration.
| Material / flammability status | The exact frame and impeller polymer trade name, resin grade and UL 94 flammability class are not confirmed by current model-specific public evidence. These values must be stated on the approved drawing and BOM before sample or production release; no generic UL94V-0 claim is applied here. |
|---|---|
| Model-specific release evidence | Approved high-speed fan drawing, frame and impeller BOM, voltage-grade current and startup limit, pressure-flow curve, acoustic condition, impeller balance or run-out evidence, wiring definition and final inspection plan. |
| Quality and traceability evidence | SXDOOL / SENSDA ELECTRONICS LIMITED applies ISO 9001:2015 quality-management controls. Dynamic Balancing and 100% End-of-Line Testing records can be reviewed against the approved production control plan for the released configuration. |
| Evidence request | Request the controlled drawing, BOM or material declaration, applicable performance curve, wiring definition and inspection record for 9238 from david@sxdool.com before qualification. |
Review quality assurance, factory capabilities, or submit a model-specific RFQ. External inquiry: david@sxdool.com.
